Description
Series:
PXI Series
Parameters and Specifications:
- Switch Bandwidth: 26.5 GHz1234
- Maximum Insertion Loss: -0.3 dB24
- Characteristic Impedance: 50 Ω12345
- Relay Type: Electromechanical124
- Maximum AC Switching Voltage: 90 VAC24
- Connector: PXI Hybrid245
- Termination: Yes1234
- Number of Channels: 6×1 (SP6T
Features:
- High Frequency: Supports up to 26.5 GHz, ideal for RF signal routing and switching1234.
- Internal Termination: Helps prevent high-power reflections from open channels within the module14.
- Relay Counting: On-board relay counting function to track relay life and reduce unexpected system downtime14.
- Flexible Routing: Connects multiple inputs to a single output or multiple outputs to a single input, simplifying wiring in automated test systems
Applications:
- Automated Test Systems: Used in various electronic, automotive, aerospace, and other industries to route RF signals in automated test setups3.
- Signal Routing: Routes RF signals from PXI RF signal upconverters to downconverters or vice versa
