NI PCI-7813R

Description

Parameters and Specifications:

• Channel Count: 8 (Analog input channels: 8 differential or 16 single-ended)¹.
• Resolution: 24 bits¹.
• Maximum Sample Rate: 500 ks/s per channel¹.
• Input Voltage Range: ±10V¹.
• Output Voltage Range: ±10V¹.
• Digital I/O Lines: 24¹.
• Counter/Timers: 2¹.
• Bus Interface: PCI¹.

Dimensions and Weight:

• Dimensions: Not specified in the search results.
• Weight: Not specified in the search results.

Series:

• NI PCI Series¹²³⁴.

Features:

• High-resolution analog I/O: With 24-bit resolution, it provides accurate data acquisition¹.
• Flexible configuration: Supports both differential and single-ended analog input¹.
• Extensive digital I/O: With 24 digital I/O lines, it offers connectivity for various digital devices¹.
• Programmable with LabVIEW FPGA: The Virtex-II FPGA can be programmed using LabVIEW FPGA modules⁵.
• Integrated triggers and timing: Supports user-defined triggers, timing, and on-board decision-making with 25 ns resolution⁵.
• On-board memory: Comes with 196 KB on-board memory and DMA data read/write for high-speed digital patterns⁵.
• Built-in examples: Includes examples for I2C, SPI, S/PDIF, RS232, and other digital communication protocols⁵.
• Self-diagnostic system: The relay-based self-diagnostic system continuously monitors the status of the relay hardware and software operations⁶.

Role:

The NI PCI-7813R is a data acquisition and control module designed for industrial automation and test applications. It provides high-resolution analog I/O, extensive digital I/O, and programmable FPGA capabilities. This module can be used in various applications where accurate data acquisition, control, and signal conditioning are required
