NI NI-9505

Description

Product Description

Product Parameters

• Voltage range: 12 V to 48 V1
• Continuous current: 50 A1
• Peak current: 100 A1
• Power: 2.5 kW1
• Interface type: Connects directly to a DC brushed motor and provides support for incremental encoder feedback5
• Compatibility: Compatible with the CompactRIO platform and suitable for use with brushed DC servo motors15

Advantages and Characteristics

• High power output: The NI NI – 9505 can output a continuous current of 50 A and a peak current of 100 A, which is sufficient to drive high – power brushed DC servo motors and meet the requirements of various industrial applications.
• Advanced control functions: With position, velocity, and torque control functions, as well as integrated encoder support, it can achieve precise control of the motor, improving the accuracy and stability of the control system.
• Reliable protection mechanisms: It has current limiting and protection, as well as fault detection and diagnostics functions, which can protect the module and the connected motor from damage in the event of abnormal conditions, improving the reliability and service life of the system.

Application Fields and Application Cases

• Applicable industries and scenarios: The NI NI – 9505 is widely used in industries such as robotics, motion control, automotive testing, and industrial automation1. It can be used to control the movement of robotic arms, the speed and position of conveyor belts in factories, and the testing equipment in the automotive industry.
• Application case: In a factory’s automated production line, the NI NI – 9505 is used to control the conveyor belt’s speed and position. By precisely controlling the brushed DC servo motor, the conveyor belt can accurately transport products to the designated location, improving production efficiency and product quality. The module’s high – power output and precise control functions ensure the stable operation of the conveyor belt under different load conditions.

Comparison with Competing Products

Selection Suggestions

• Compatibility: Ensure that the selected module is compatible with your existing equipment, especially the CompactRIO platform and the brushed DC servo motor you plan to use.
• Installation environment: Consider the installation space and environmental conditions. The NI NI – 9505 has dimensions of 104 mm x 85 mm x 23 mm and a weight of 0.4 kg, so make sure there is enough space for installation1. Also, pay attention to factors such as temperature and humidity to ensure the normal operation of the module.
• Budget: The price of the NI NI – 9505 should be within your budget. However, don’t just focus on the price but also consider the overall performance and reliability to ensure you get the best value for your money.

Precautions

• Safety regulations: Operate the NI NI – 9505 only as described in the operating instructions3. When installing in a potentially explosive environment, follow the relevant safety guidelines to avoid serious injury or death3. Do not disconnect the I/O – side wires or connectors, or remove the module unless the power has been switched off or the area is known to be non – hazardous3.
• Maintenance suggestions: Regularly check the connection status of the module and the motor to ensure reliable contact. Clean the module regularly to prevent dust and dirt from affecting its performance. Also, monitor the operating temperature and current of the module to detect and handle any potential problems in a timely manner.
