N0150ZC

Description

Parameter Specifications

Power Supply: The N0150ZC typically operates on a 12 – 24V DC power supply. This wide – range power input provides flexibility in different electrical setups, with a power consumption of approximately 1 – 2W, ensuring energy – efficient operation.
Input/Output Channels: It is equipped with a specific number of digital input and output channels. For example, it may have 4 digital input channels to detect signals from sensors like limit switches or proximity sensors, and 2 digital output channels to control devices such as small relays or indicator lights.
Communication Interface: It features a serial communication interface, usually RS – 485, supporting Modbus RTU protocol. This allows seamless integration with other industrial devices and control systems for data exchange and remote monitoring.
Operating Temperature Range: Designed to function in a wide temperature range, from – 10°C to 50°C, making it suitable for various industrial environments.

Applications

Industrial Automation: In small – scale manufacturing processes, it can be used to control and monitor simple machinery. For instance, it can control the movement of a conveyor belt based on the presence of products detected by input sensors.
Building Automation: In residential or small – commercial buildings, it can be used for basic control tasks such as controlling the opening and closing of blinds based on light sensors or monitoring the status of door locks.
Agricultural Automation: In greenhouse automation, it can monitor environmental parameters like temperature and humidity sensors and control ventilation fans or heaters accordingly.

Weight and Dimensions

Weight: Approximately 0.1 kg, which is very light and easy to handle during installation and maintenance.
Dimensions: It has a compact design, with dimensions of about 50mm (length) x 40mm (width) x 20mm (height). This small size allows it to be easily installed in tight spaces, such as inside control boxes.
Features
Compact and Lightweight: Its small size and low weight make it easy to integrate into various systems without taking up much space.
Easy Configuration: Configuration is simple, often through software or DIP switches. Users can quickly set up input/output functions, communication parameters, and other settings according to specific requirements.
Cost – Effective: It offers a cost – effective solution for basic automation and control tasks, especially for small – scale applications where high – end features are not required.

Stability and Reliability

Solid Construction: Built with quality components and a durable enclosure, it can withstand normal industrial vibrations and minor impacts.
Electrical Isolation: It provides electrical isolation between input/output channels and the power supply, protecting the device from electrical interference and ensuring stable signal transmission.
Long – term Testing: Through long – term testing, it has been proven to have a reliable performance over time, with a low failure rate.

Practical Case

In a small – scale woodworking workshop, the N0150ZC is used to control a simple sawing machine. The digital input channels are connected to a proximity sensor that detects the presence of wood on the sawing table. When the sensor detects wood, the N0150ZC sends a signal through the digital output channel to start the saw. One day, there was a brief power surge in the workshop. However, due to the electrical isolation feature of the N0150ZC, the device continued to operate normally, and the sawing process was not interrupted. The cost – effective and reliable performance of the N0150ZC ensured the smooth operation of the woodworking process.
