Description
Parameters and specifications
Processor: Supports a wide range of processor options, including MPC7410, MPC750 or MPC755 class microprocessors that offer high performance and low power consumption.
Cache: Has 32KB L1 cache and can be equipped with secondary back-end cache up to 2MB.
Front-end bus speed: 100 MHz.
Memory: 128 MB SDRAM is supported, and memory can be increased with memory sandwich cards up to 1 GB.
Storage: Usually comes with a 2 GB IDE hard drive or solid state drive.
I/O interface: Provides a variety of interfaces, including two RS-232C serial ports, 10/100BaseTX Ethernet interface.
Expansion capability: It has 1 PCI slot and 1 CompactFlash slot, and supports rich peripheral expansion.
Network: Supports dual 10BaseT/100BaseTX Ethernet interfaces, providing high-speed network communication capabilities.
Operating temperature: The commercial version has an operating temperature range of 0° to 55°C, while the extended temperature version has an operating temperature range of -20° to 71°C.
Size and weight
Dimensions: 233 mm x 160 mm x 40 mm.
Weight: 1.36 kg
trait
High Performance: Based on the PowerPlus II architecture, it supports a wide range of high performance processor options.
High bandwidth: Integrated highly optimized PCI interface and memory controller, providing up to 582MB/s memory read bandwidth and 640MB/s burst write bandwidth.
Flexible expansion: With PCI slot and CompactFlash slot, support for rich peripheral expansion.
Multi-field applications: suitable for industrial control, data acquisition, communications, aerospace and medical imaging and other application scenarios.
