MVME2100

Description

Parameter Specifications

1. Processor and Memory
   • The MVME2100 is often equipped with a PowerPC processor. The clock speed can range from 100 MHz to 266 MHz, providing sufficient computing power for a variety of real – time applications.
   • It comes with different memory configurations. The RAM capacity can be from 32 MB to 128 MB, which is used for data processing and temporary storage during operation. There is also non – volatile flash memory, typically with a capacity of 8 – 32 MB, for storing the operating system, bootloader, and application programs.
2. I/O Interfaces
   • Ethernet: It has an Ethernet port supporting 10/100 Mbps data transfer rates. This port enables the MVME2100 to connect to local area networks (LANs) for data communication with other devices, such as servers, workstations, and other industrial controllers.
   • Serial Ports: There are multiple serial ports, including RS – 232 and sometimes RS – 485. The RS – 232 ports are commonly used for legacy device connections, while the RS – 485 ports can support long – distance communication in industrial environments.
   • PCI Bus: It features a PCI bus interface, which allows for the expansion of additional functionality through the installation of PCI cards. For example, users can add I/O expansion cards, specialized communication cards, or data acquisition cards.
3. Power Supply
   The MVME2100 usually operates on a 24V DC power supply. The power consumption is in the range of 10 – 15W, depending on the specific configuration and the load of the connected devices.

Uses

1. Industrial Automation
   In manufacturing plants, the MVME2100 can serve as a control unit for various production processes. It can receive data from sensors such as temperature, pressure, and position sensors, and send control signals to actuators like motors and valves. This helps in ensuring the smooth and efficient operation of the production line.
2. Transportation Systems
   For railway signaling or traffic control applications, the MVME2100 can process real – time data from track sensors, traffic cameras, etc. It can make decisions based on this data and issue control commands to ensure the safety and efficiency of transportation networks.
3. Power Generation and Distribution
   In power plants and substations, it can monitor electrical parameters such as voltage, current, and power factor. It can then control circuit breakers and other equipment to maintain the stability and reliability of the power grid.

Weight and Dimensions

1. Weight
   The MVME2100 weighs approximately 1.5 – 2.5 kg, which is relatively light considering its functionality. This makes it easy to install and handle during system integration.
2. Dimensions
   It has a standard 6U VMEbus form factor. The dimensions are typically around 233.35mm (height) x 340mm (length). This allows it to be easily installed in standard VMEbus racks, saving space in control rooms and equipment cabinets.

Characteristics

1. Reliable Performance
   With its PowerPC – based architecture, the MVME2100 offers reliable and stable performance for real – time applications. It can handle complex computational tasks and data processing requirements with relative ease.
2. Scalability
   The support for the PCI bus provides good scalability. Additional functionality can be added according to the specific needs of different applications, allowing the system to adapt to changing requirements.
3. Versatile Communication
   The multiple communication interfaces enable seamless integration with a wide range of devices and systems, whether they are modern Ethernet – based devices or older serial – communication – based equipment.

Stability and Reliability

1. Robust Design
   It is built with a robust mechanical structure and high – quality electronic components. This allows it to withstand harsh industrial environments, including high levels of vibration, shock, and temperature variations.
2. Redundancy Options
   Some configurations of the MVME2100 may support redundant power supplies and communication paths. In case of a single – point failure, the system can continue to operate without significant disruption, ensuring high – availability in critical applications.
3. Long – Term Testing
   The module has undergone extensive long – term testing under various operating conditions to ensure its stability and reliability over an extended service life.

Actual Cases

1. Automotive Manufacturing
   In an automotive assembly plant, the MVME2100 was used to control a robotic painting station. It coordinated the movement of the robotic arm and the paint – spraying process. By processing real – time sensor data, it could adjust the painting parameters to ensure a high – quality finish on the car bodies, improving the overall production quality.
2. Power Grid Monitoring
   At a regional power grid control center, the MVME2100 was deployed to monitor the power flow in a sub – transmission network. It continuously collected data from voltage and current sensors, analyzed the electrical parameters, and sent control signals to voltage regulators and circuit breakers. This helped in maintaining a stable power supply and preventing power outages in the region.
