MVME162-212

Description

3. Weight and Dimensions

• Weight: The MVME162 – 212 weighs approximately 1.4 kg. Its weight is manageable for installation and maintenance, especially when it needs to be installed in a rack – mounted system.
• Dimensions: It has dimensions of around 210 mm in length, 150 mm in width, and 40 mm in height. These compact dimensions allow it to be easily installed in standard 19 – inch racks, which are commonly used in industrial and data – center environments.

4. Features

• Compact Design: The small form factor of the MVME162 – 212 makes it suitable for applications where space is limited. It can be easily integrated into existing systems without taking up excessive space.
• Versatile I/O Interfaces: The multiple I/O interfaces provide flexibility in connecting to different types of devices and systems. This allows for seamless integration into various industrial, transportation, and power – generation applications.
• Real – Time Processing: The Motorola 68040 processor enables real – time processing of data, which is crucial for applications that require immediate response to changing conditions, such as control systems and monitoring systems.

5. Stability and Reliability

• Robust Construction: The MVME162 – 212 is built with a durable housing that can withstand harsh environmental conditions, including high temperatures, humidity, dust, and mechanical vibrations.
• Quality Components: It uses high – quality electronic components that are selected for their reliability and long – term performance. These components are tested rigorously to ensure they can operate under extreme conditions.
• Redundancy Options: Although not always standard, in some critical applications, redundancy options can be implemented. For example, redundant power supplies and communication paths can be set up to ensure continuous operation in case of a component failure.

1. Parameter Specifications

• Processor: The MVME162 – 212 is powered by a Motorola 68040 processor. It typically operates at a clock speed of 25 MHz or 33 MHz, providing sufficient processing power for real – time applications.
• Memory:
  • RAM: It comes with a standard 4 MB of static RAM (SRAM), which can be expanded up to 16 MB. The SRAM offers fast data access, enabling quick execution of programs and handling of real – time data.
  • ROM: There is 2 MB of flash ROM for storing the boot code, operating system, and application software. This non – volatile memory ensures that the system can boot up and run even after a power cycle.
• I/O Interfaces:
  • Serial Ports: It has two serial ports, RS – 232 and RS – 422/485. These ports support various communication protocols and are useful for connecting to legacy devices, sensors, and other serial – based equipment.
  • Ethernet: An Ethernet port is available, supporting 10 Mbps Ethernet communication. This allows the MVME162 – 212 to be integrated into local area networks (LANs) for data transfer and remote access.
  • PCI Bus: It features a PCI bus interface, which enables the addition of expansion cards for enhanced functionality, such as additional I/O modules or specialized communication cards.
• Power Supply: The module operates on a 5V DC power supply with a power consumption of around 10 – 15W, which is relatively energy – efficient for its processing capabilities.

2. Applications

• Industrial Automation: In manufacturing plants, the MVME162 – 212 is used for controlling and monitoring industrial processes. For example, in a paper – making plant, it can control the operation of the paper – making machine, monitor the quality parameters such as paper thickness and moisture content, and adjust the process parameters accordingly.
• Transportation: In railway systems, it can be used for train control and monitoring. It can receive data from sensors on the train, such as speed sensors and brake sensors, and send control signals to the train’s actuators to ensure safe and efficient operation.
• Power Generation: In power plants, the MVME162 – 212 can be used for controlling and protecting power generation equipment. It can monitor the electrical parameters of generators, such as voltage, current, and frequency, and take appropriate actions in case of faults, such as tripping circuit breakers.

6. Real – World Examples

• Automotive Assembly Line: In an automotive assembly line, the MVME162 – 212 is used to control the movement of robotic arms. It receives data from sensors that detect the position and orientation of car parts, and based on this data, it sends control signals to the robotic arms to perform precise assembly tasks. The real – time processing capabilities of the MVME162 – 212 ensure that the robotic arms can respond quickly to changes in the assembly process, improving the efficiency and quality of production.
• Hydroelectric Power Plant: In a hydroelectric power plant, the MVME162 – 212 is used to monitor and control the operation of the turbines. It measures the water flow rate, pressure, and turbine speed using sensors connected to its I/O interfaces. If any of these parameters deviate from the normal range, the MVME162 – 212 can take corrective actions, such as adjusting the turbine blades or shutting down the turbine in case of an emergency. The stability and reliability of the MVME162 – 212 are essential for the safe and efficient operation of the power plant.
