MVME162-212

Description

dimension
Overall dimensions: 450 x 364 x 80 mm (W x H x D).
Box shape: 418 x 332 x 72 mm (W x H x D).
Cabinet openings: 421 x 335 mm (W x H).
weight
Machine weight: 6Kg.
Another claim is that the weight is 2KG, which may refer to the weight of individual components or different models.
series
The MVME162-212 is part of a series of industrial-grade computer modules or data acquisition CPU boards produced by MOTOROLA.

specification
Mechanism parameters:
Front panel: aluminum magnesium alloy material, IP65 protection grade.
Box structure: aluminum magnesium alloy material, surface oxidation treatment, beautiful and light, with good heat dissipation performance.
Installation mode: Support panel, wall mount, cantilever and other installation modes.
System parameters:
Processor architecture: Socket 479 architecture.
Chipset: Intel 855GM/GME&6300ESB.
Disk support: Type II CF card, DOM, 2.5″ laptop hard disk.
Display: 2D/3D graphics acceleration, 64M dynamic memory, support dual screen display.

argument
Processor: Support Intel Pentium/Celeron M low power processor, including different models of processor options, such as CM600MHz, PM1.1GHz, PM1.5GHz, etc.
Memory: Supports a maximum of 1GB DDR memory.
Display:
Display: 17″ SXGA TFT LCD, resolution 1280×1024, brightness 300cd/m2.
Touch screen: Industrial eight-wire resistive touch screen, resolution 4096×4096.
Interface:
USB: Six USB2.0 ports.
Serial port: 4 RS232 ports.
Parallel port: One parallel port, supporting SPP/EPP/ECP modes.
Network port: 1/2 RJ45 ports of 10 to 100M are optional.
Audio: LINE-out, MIC-in.
PS/ 2:1 PS/2 keyboard and 1 PS/2 mouse.
Expansion slot: One PCI expansion slot.
Power supply: 100V~240V AC voltage input.
