MVI69-PDPS

Description

–‌Series‌: ProSoft MVI69 Series

–‌Parameters‌:

• Communication Protocol: PROFIBUS DP, DP-v11
• Data Transmission Rates: Supports standard communication rates up to 12MBit/s23
• Power Supply: Typically 24V DC4, but also supports DC9-36V wide range with redundancy3

–‌Specifications‌:

• Configurable data mapping and DP port operations2
• Supports CompactLogix and MicroLogix 1500 LRP controllers (excluding certain models)2
• Advanced fault diagnosis and monitoring capabilities2
• IP30 protection rating with rugged aluminum housing3

–‌Dimensions and Weight‌:

• Dimensions: 4.88″ x 2.87″ x 1.77″ (Length x Width x Height)1
• Weight: Approximately 0.33 pounds (based on size)1, but may vary with packaging and accessories

–‌Features‌:

• Easy connection between CompactLogix I/O compatible processors and PROFIBUS DP master devices2
• Flexible module configuration supporting multiple controllers2
• Strong data transmission and diagnostic capabilities2
• Industrial-grade design with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection3

–‌Functions‌:

• Enables seamless communication between different industrial automation systems and devices2
• Facilitates data transmission and fault diagnosis, enhancing system reliability and performance2
• Supports the integration of PROFIBUS DP networks into existing industrial automation infrastructures
