Description
Parameter Specifications:
Compatibility: Designed for use with Rockwell Automation ControlLogix Programmable Automation Controllers (PACs).
Ethernet Capability: Supports up to 20 Siemens S7 series PLCs (S7-200, S7-300, S7-400, S7-1200, and S7-1500) as Ethernet servers.
Data Transfer: Utilizes scheduled I/O data for faster updates and enhanced performance.
Port Speed: 10/100 Mbps auto-crossover detection for Ethernet configuration and application ports.
Functions:
Communication Bridge: Acts as a communication bridge between ControlLogix PACs and Siemens S7 series PLCs.
Configuration Management: Uses ProSoft Configuration Builder (PCB) for graphical configuration and management of module profiles.
Weight & Dimensions:
Weight: Specific weight is not detailed, but it is designed for industrial use and is likely to be lightweight for easy installation.
Dimensions: Dimensions are not provided, but the module is designed to be single-slot compatible with the 1756 ControlLogix backplane.
Features:
User-Defined Memory Mapping: Allows for up to 5000 user-defined 16-bit registers for module data storage.
High Compatibility: Compatible with ControlLogix 1756-ENxT and 1756-CNB modules.
Diagnostic Tools: Provides access to communication and module diagnostic information via high-speed Ethernet ports.
Application Areas:
Industrial Automation: Ideal for use in industrial automation systems requiring seamless communication between different PLC brands.
Manufacturing: Suitable for manufacturing environments where integration of diverse automation equipment is crucial
