Description
Specifications and Parameters:
Communication Protocols: Supports Modbus TCP/IP, EtherNet/IP, and DF1, enabling seamless integration with various industrial networks and devices.
Operating Temperature: Designed to operate within a wide range of -40°C to 85°C, ensuring reliability in diverse environmental conditions1.
Storage Temperature: Similar to the operating temperature, the storage range is also -40°C to 85°C1.
Interface: Features four independent Ethernet interfaces and an integrated network switch, facilitating robust network connectivity1.
Modbus Capability: Allows Modbus master/slave connections from Rockwell Automation ControlLogix processors to Modbus RTU/ASCII devices2.
Function:
The MVI56E-MCM serves as a bridge between different industrial devices and systems, enabling data communication and integration.
It is used in factory automation systems to communicate with sensors, actuators, and controllers, facilitating production line monitoring, control, and optimization3.
Weight and Dimensions:
Weight: According to one source, the weight is specified as 0.91kg1. However, please note that different sources or product variants may have slight variations.
Dimensions: Measuring 117mm x 43mm x 129mm, the MVI56E-MCM offers a compact design suitable for various installation scenarios1.
Additional Features:
Provides up to 10,000 16-bit registers for user-defined module data memory mapping2.
Features a 4-character, scrolling, alphanumeric LED display for easy status and diagnostic data readout2.
Supports Remote Insertion and Removal Under Power (RIUP), enhancing maintenance efficiency
