MVI56E-MCM

Description

argument
Supported protocols: Modbus RTU/ASCII, Modbus TCP/IP, EtherNet/IP, etc.
Configuration capability: Each MVI56E port can be configured as a host or slave.
Storage capacity: User-definable modular data memory mapping of up to 10,000 16-bit registers.
Network configuration: 10/100 MB Ethernet port for network configuration and diagnostics with automatic cable cross detection.
specification
Operating temperature: Designed for standard process applications, the MVI56E-MCMXT is designed for the Logix-XT control platform, allowing operation in extreme environments.
Compatibility: Backward compatible with previous MVI56-MCM versions, replacement can be done without changing existing controller programs.
Display and diagnosis: 4-character, scrolling, alphanumeric LED display displays status and diagnostic data in plain English.
​
trait
High-performance communication: Supports a variety of communication protocols and network topologies, including star, ring, bus, etc.
Flexible configuration: Each port can be configured independently as a master or slave port, providing great flexibility.
Powerful backplane function: Can be used as the ControlLogix backplane, so that Modbus data is displayed as processor I/O data.
Harsh environment adaptability: The MVI56E-MCMXT has a conformal coating that protects it from harsh or corrosive conditions.
Rich diagnostic functions: Equipped with a debugging/configuration port in the form of an RJ45 Ethernet port, supporting 10/100 base-T transmission speed.
