Description
Features:
Modbus Conversion: Converts ControlLogix PLC instructions and data to Modbus protocol for seamless communication with Modbus devices1.
Redundancy and Diagnostics: Provides redundancy configuration and diagnostic monitoring functions for enhanced system reliability3.
Robust Design: Industrial-grade design ensures high stability and reliability in harsh industrial environments1.
Flexible Address Mapping: Allows mapping of ControlLogix data to Modbus device registers1.
Applications:
Data Acquisition: Collects data from multiple Modbus devices and transmits it to the PLC for processing1.
Remote Control: Enables remote control of connected Modbus devices through the PLC1.
Industrial Automation: Widely used in industrial automation systems for connecting PLCs with Modbus devices such as frequency converters, sensors, and actuators
Parameters and Specifications:
Communication Protocol: Modbus RTU and Modbus ASCII, enabling seamless communication between Rockwell Automation ControlLogix PLCs and Modbus-compliant devices1.
Data Transmission: High-speed data transmission capabilities, suitable for industrial control systems requiring real-time performance2.
Configuration Flexibility: Offers flexible configuration options for various communication parameters such as baud rate, data format, and addressing modes3.
Ports: Includes RS-232 and RS-485 serial ports for connecting various serial devices1.
Register Space: Supports up to 5000 word registers for data exchange between the processor and Modbus network4.
Dimensions and Weight:
Dimensions: Specific dimensions are not provided, but it is designed for installation on remote racks, suggesting a compact form factor suitable for industrial environments.
Weight: Approximate weight is not specified, but as an industrial communication module, it is likely to be lightweight and portable for easy installation and maintenance.
