MVI56-BAS

Description

‌Parameters & Specifications‌:

–‌Power Supply‌: Operates on 24VDC, with a current consumption of 150mA12.
–‌Communication Interfaces‌: Equipped with DH-485, PRT1, and PRT2 ports for communication, BASIC program transmission, ASCII communication, programming, or DF1 communication34.
–‌Memory‌: Has 24065 bytes of available RAM34.
–‌Temperature Range‌: Operates within a temperature range of -40°C to +85°C12.
‌Dimensions & Weight‌:

–‌Dimensions‌: Measures approximately 117mm x 43mm x 129mm1. Alternatively, dimensions of 4.88 cm x 14.73 cm x 14.48 cm are also reported2.
–‌Weight‌: Weighs approximately 0.91kg1. However, a weight of 2KG is also mentioned, which could be due to different configurations or packaging5.
‌Series‌:

• Belongs to Prosoft Technology’s communication module series
•
  ‌Features‌:

–‌BASIC Program Conversion‌: Converts traditional BASIC programs used on 1747-BAS and 1771-DB modules to ControlLogix systems34.
–‌Compact Flash Slot‌: Incorporates a compact flash (CF) card slot for storing BASIC programs, which can also be exported to other devices or local PCs34.
–‌Configurable Communication Modes‌: Can be configured as a DF1 half-duplex slave or DF1 full-duplex module34.
–‌LED Status Indicators‌: Equipped with four LED status indicators for module operation, backplane transmission, application, and serial activity34.
–‌Protocol Support‌: Supports Modbus TCP/IP, making it compatible with various automation systems12.
‌Functions & Applications‌:

–‌Data Transmission‌: Enables data transmission between the MVI56-BAS module and ControlLogix processors34.
–‌External Device Interface‌: Creates external device interfaces for special applications, allowing connection of devices like printers, barcode readers, or modems to the ControlLogix backplane34.
–‌Automation & Control‌: Used in automation and control systems to improve production efficiency and product quality by enabling precise control and monitoring
