MR-J2S-350B-EG171

Description

2. Product Parameters

• Power Supply: 3 – phase 200 – 230 VAC, 50/60 Hz4.
• Permissible Voltage Fluctuation: 3 – phase 170 – 253 VAC4.
• Current Rating: 2.3 A5.
• Control Method: Pulse train/analog voltage5.
• Feedback Device: Incremental encoder5.
• Ambient Temperature (Operation): 0 – 55 °C (32 – 131 °F)4.
• Ambient Temperature (Storage): – 20 – 65 °C (- 4 – 149 °F)4.
• Ambient Humidity (Operation and Storage): 90% RH or less (non – condensing)4.
• Altitude: Max 1000 m (3280 ft) above sea level4.
• Dimensions (W x H x D): 9 cm x 16.8 cm x 19.5 cm4.
• Weight: 2 kg4.

3. Advantages and Characteristics

• High Precision: The use of sine – wave PWM control and advanced current control technology enables the MR – J2S – 350B – EG171 to achieve precise motor control, ensuring smooth and accurate movement4.
• Reliable Performance: It has a robust construction and can withstand harsh operating conditions5. With built – in overcurrent protection, thermal protection, and emergency stop capabilities, it ensures safe operation in critical applications5.
• Easy Integration: Equipped with versatile communication options, it supports a range of communication protocols, facilitating easy integration with various automation systems5.
• Energy – efficient: Designed with energy efficiency in mind, it minimizes power consumption while maximizing performance, helping to reduce operational costs5.

4. Application Fields and Application Cases

• Application Fields: The MR – J2S – 350B – EG171 is widely used in various industrial fields, including robotics, CNC machinery, packaging equipment, and material handling5. In the robotics industry, it ensures precise control and movement of robotic arms and automated handling systems. In CNC machinery, it provides accurate motion control for CNC mills, lathes, and other machine tools5.
• Application Case: In a packaging factory, the MR – J2S – 350B – EG171 is used to control the servo motors of the packaging and labeling machines. It enables high – speed and accurate packaging and labeling operations, improving production efficiency and product quality. With its precise control, the machines can handle different packaging materials and product sizes with ease

5. Competitor Comparison

6. Selection Suggestions

• Compatibility: Make sure that the MR – J2S – 350B – EG171 is compatible with your existing equipment and control system, including servo motors, PLCs, and other related components.
• Installation Environment: Consider the installation environment, such as ambient temperature, humidity, and altitude. Ensure that the environment meets the requirements of the product to ensure its normal operation2.
• Budget: Although the MR – J2S – 350B – EG171 offers high performance and reliability, it is also necessary to consider the budget. Evaluate the cost – effectiveness of the product based on your actual needs.

7. Precautions

• Electrical Safety: Before wiring or inspection, turn off the power and wait at least 15 minutes for the charge lamp to turn off. Use a voltage tester to confirm that the voltage is safe2. Always ground the servo amplifier and servo motor to avoid electric shock2.
• Mechanical Safety: Install the servo amplifier and servo motor on incombustible material2. Avoid placing heavy objects on the equipment or using it to support other loads. Ensure proper clearance around the amplifier to facilitate cooling and prevent overheating2.
• Maintenance: Regularly check the connections and components to ensure they are in good condition2. Replace the electrolytic capacitors in the servo amplifier every 10 years to prevent potential failures2.
