Description
Parameters and specifications:
Processor:
MPC7410 @ 400 MHz (PowerPC 64-bit processor, PowerPC 7448, or MPC7457 in some sources, the frequency may vary).
Equipped with AltiVec coprocessor for high performance computing applications.
Memory:
DDR SDRAM, up to 2GB.
In some specifications, the memory may be DDR2 SDRAM.
Storage space:
Storage may vary, such as 8GB (up to 4GB flash in some materials).
Interface:
VME64x.
Gigabit Ethernet interface.
Series:
MOTOROLA’s line of embedded systems or single-board computers.
Features:
High performance: With high performance processor and rich memory configuration, it can handle complex computing tasks.
Reliability: Designed for stable operation in industrial environments, with seismic, dustproof, moisture-proof and other characteristics.
Versatility: Supports multiple operating systems (such as Linux and VxWorks) and provides multiple I/O interfaces to meet different application requirements.
Extensibility: Additional features or interfaces can be added through slots or expansion cards.
Functions:
The MOTOROLA MVME5500 is suitable for a variety of embedded applications that require high performance and reliability, including but not limited to industrial automation, robotics, aerospace and defense, medical devices, communications systems, and more. It can provide powerful processing power, reliable running performance and rich functions for these applications, and help users build high-performance and perfect embedded systems.
USB 2.0 port.
Serial interface (RS-232/422/485).
The PCI bus.
Other I/O interfaces such as Universe II VME interface, PMCspan connector, parallel port, etc.
Working conditions:
Operating temperature: 0°C to 60°C, there are also references to -40 °C to 85 °C.
Storage temperature: -40°C to 85°C.
Humidity: 10% to 90% non-condensing.
Shock and vibration resistance: Specific parameters such as 30G, 11ms shock and 0.2G, 5Hz to 500Hz vibration.
Size and weight:
Size:
233mm x 160mm x 45mm (233mm x 160mm x 43mm in some sources).
Weight:
500 grams
