MOOG G123-825-001 is a buffer amplifier designed for connecting and interfacing with standard signal sources such as PLCs or servo amplifiers, along with MOOG servo proportional valves. Here is a breakdown of its parameters, specifications, dimensions, weight, series, features, and functions in English:
Parameters:
Input Signals: The G123-825-001 accepts a range of input signals, including analog signals (±10 V, 4-20 mA), and digital signals (pulse width modulation, PWM).
Output Signals: The output signal is a current signal with a maximum of 2.5 A.
Specifications:
Power Supply: The G123-825-001 requires either a 24 VDC or 30 VDC power supply.
Power Consumption: The maximum power consumption is 40 W.
Operating Temperature: The operating temperature range is from -20°C to 60°C.
Dimensions and Weight:
Dimensions: The G123-825-001 measures 150 mm x 85 mm x 45 mm.
Weight: The weight of the buffer amplifier is approximately 0.5 kg.
Series:
The G123-825-001 belongs to the MOOG G series servo amplifier family.
Features:
Signal Enhancement: The buffer amplifier enhances the input signal amplitude to a suitable level for system processing.
Signal Buffering: It buffers the signal to prevent signal loss or degradation.
Low Noise: The design provides low-noise signal amplification.
High Input Impedance: This feature helps avoid any adverse effects on the input signal source.
Switchable Gain: Some models allow users to adjust the gain to meet different application requirements.
Filter: A built-in filter removes noise from the input signal, with a switchable filtering time constant.
Versatile Output Options: The output signal can be switch-selected to be fixed 4 to 20 mA, 0 to ±10 V, or selectable 0 to ±5 to ±100 mA, suitable for different valve types.
Functions/Applications:
Signal Interface: The G123-825-001 interfaces between PLCs or servo amplifiers and MOOG servo proportional valves, resolving compatibility issues between signals and valve requirements.
Replacement of Old Valves: It allows the replacement of older mechanical feedback (mfb) valves with modern electrical feedback (efb) valves without requiring servo amplifier replacement.
Electronic, Electrical, or Motion Control Systems: The buffer amplifier is used to enhance signals, improve signal-to-noise ratio, and buffer signals to meet the demands of various control systems.
