Description
trait
Encoder: With digital servo feedback motor encoder, integrated multi-turn JUE pair encoder
Output shaft: equipped with ordinary shaft output shaft (with shaft seal)
Cooling method: Traditional cooling method
Temperature range: The permissible storage and transport temperature range is -20 to 80 degrees Celsius, with a maximum permissible ambient temperature of 40 degrees Celsius
Overtemperature rating: set to 60 k and 100 k
Control characteristics: High efficiency, low maintenance, high precision control
Parameters and specifications
Motor frame size: 82 mm flange size
Centering diameter: 50 mm
Motor frame length: Although “2.7 Nm” is mentioned, this may be a misunderstanding of a certain feature, but the actual length should be specific (but the specific value is not directly given).
Continuous static torque: 1.35Nm
Characteristic speed: 7,000 RPM
Rated speed: 4,000 RPM at 540 V DC
Winding inductance: 13.5mH (mentioned in some cases)
Peak current: 15.8A (mentioned in some cases)
Output power and feedback connection: can rotate 270 degrees
Moment of inertia: 0.88 x 10^-4 kgm^2 (mentioned in some cases)
Theoretical maximum torque: 5.6 Nm (mentioned in some cases)
dimension
Motor frame size: As mentioned above, the flange size is 82 mm and the centering diameter is 50 mm
weight
Weight: 2.9Kg (without brakes or fan unit)
