Description
Parameters and specifications
Input voltage range: 19.2 to 30 VDC
Input current: 7 mA per channel
Input impedance: 3.1 kilohm
Input signal voltage: 0 to 30 VDC
Input signal current: 0.5mA
Isolation voltage: 1500 VDC (between channels)
Surge voltage: 1 kV (1.2/50μs)
Operating temperature range: -40°C to +70°C
Storage temperature range: -40°C to +85°C
Processor: 32-bit processor capable of handling complex control applications
Memory: 256 MB RAM and 512 MB flash memory
Communication: Support Ethernet, serial, USB and other communication options
Input/output: 22 digital inputs and 22 digital outputs, as well as 4 analog inputs and 2 analog outputs
Power supply: 24V DC power supply is required
Size and weight
Weight: 2KG
series
The MC-PDIY22 belongs to a family of Honeywell products specifically designed for industrial control systems.
trait
High accuracy and reliability: The module has high precision signal acquisition and conversion capabilities to ensure accurate and reliable signal input.
Versatility: With multiple digital input and output channels, as well as analog input and output channels, suitable for a wide range of industrial control applications.
Easy communication: supports a variety of communication protocols and interfaces to facilitate data exchange and communication with other devices and systems.
Configuration and monitoring: Supports configuration and monitoring functions for users to set and monitor channels.
effect
MC-PDIY22 is mainly used to input switching state or discrete signals into the control system to achieve communication and data exchange with other devices. It plays a key role in industrial automation systems, providing control and monitoring functions for various industrial equipment. In addition, the module also has a temperature detection function, which can reflect the temperature of the card in the FSC system, and provide information such as the type of card fault, Rack number and Position number through the diagnostic display function.
