Description
Specifications:
Rated Insulation Voltage: 380V
Rated Current: 240A or up to 630A
Breaking Capacity: 100KA or up to 70KA
Arc Extinguishing Medium: Magnetic Blow-out Type
Tripper Type: Thermal-magnetic
Series: NZM Series
Protection Types: Overload Protection (Thermal Protection), Short-circuit Protection (Magnetic Protection)
Functions:
Provides flexible protection schemes for low-voltage distribution systems and equipment
Offers various protection functions, such as distribution, motor protection, generator protection, leakage, and grounding protection
Weight:
Approximately 12kg
Dimensions:
Overall dimensions may vary depending on specific models and configurations. Some sources mention an overall size of 5515mm, but this could be a typo or specific to a certain part. For exact dimensions, please consult official product documentation.
Characteristics:
Compact structure with powerful functionalities
Meets IEC60947-2 and GB14048-2 standards
Possesses CE marking and CCC certification
Offers a full range of accessories, including various terminals, drawers, plug-in bases, mechanical interlocks, and handles
Applications:
Designed for electrical systems up to 630A
Suitable for low-voltage distribution systems and equipment, providing optimized designs for systems and equipment with a breaking capacity of up to 70kA
Widely applied in distribution, motor protection, generator protection, leakage, and grounding protection
