Description
Parameters and specifications:
Input type: Support AC or DC input, AC voltage range is 85~264 VAC, DC voltage range is 90V~350V.
Output power: 500W.
Output voltage and current: Depending on the channel, for example, the output voltage of channel 1 is 24.7VDC and the output current is 20A.
Accuracy level: The accuracy level of current and voltage is 0.2.
Other parameters: Insulation resistance ≥100MΩ, power frequency voltage tolerance is 3kV/1min(RMS) between the power terminal group and the signal input and output terminal group, the average trouse-free working time is ≥50000h.
Size and weight:
Size: The length is 194mm, the width is 113.6mm, and the height has two versions, one is 138mm and the other is 18mm.
Weight: Approximately 2.8kg.
Features:
Stable power supply: Designed to provide a stable and reliable power supply to meet the electrical energy needs of the equipment in the automation system, converting the input power supply into a stable output voltage and current suitable for the equipment.
Modular design: Easy to install, maintain and replace, and easy to expand the system’s power capacity as needed.
Energy efficient: With efficient energy conversion technology, designed to reduce energy consumption and operating costs.
