Description
Parameters and Specifications:
-Power Supply: 24V DC, with a range of 20.4V to 30V
-Output Current: Each output rated at 500mA, with a peak current of 2A for 1 second
-Memory: Equipped with 128MB NVRAM, 512MB RAM, and a 512MB SD card for data storage
-I/O Capabilities: 20 discrete I/O points, including 12 total inputs, 8 normal inputs, 4 capture inputs, and 8 discrete outputs
Dimensions and Weight:
-Dimensions: 45mm (width) x 220mm (depth) x 230mm (height)
-Weight: 2.2kg
Features:
-High Performance: Provides synchronous axis motion control, speed control, high-speed counting, and communication network capabilities2.
-Scalability: Fully scalable and expandable to meet varying machine requirements2.
-Certifications: Compliant with CE, CSA, and UL standards, meeting UL 508 and CSA C22.2 No. 1422.
-Programming Flexibility: Supports a range of programming languages, including sequential function charts, ladder diagrams, and structured text1.
-Protection: Equipped with short-circuit protection for outputs1.
