Description
argument
Rated power supply voltage: AC100V~240V, power supply voltage allowable range: AC85~264V.
Frequency: 50/60HZ.
Allowable instantaneous power failure range: For instantaneous power failure below 10ms, the action will continue.
Power fuse: AC250V 5A.
Impulse current: Maximum 30A (under 5ms /AC100V) or maximum 65A (under 5ms /AC200V).
Power consumption: 34W.
DC24V external supply output: 1200mA.
Input points: 32 points.
Input signal voltage: DC24V+10%.
Input signal current: X0~X7 is 7mA/DC24V, other is 5mA/DC24V.
ON state current: X0~X7 is more than 4.5mA, other is more than 3.5mA.
OFF Current: less than 1.5mA.
Input response time: X0~X17 with digital filtering function, filtering time can be set between 0~60ms by user programming, other 10ms.
specification
Shock resistance: 10 to 55 Hz, double amplitude 1.5 mm, X,Y,Z direction 2 hours each.
Impact resistance: 1,000 m/s² (IEC60068-2-27).
Enclosure protection level: IP67G (JIS), IP67 (IEC), NEMAType13.
Ambient temperature: -10 to +55 °C (without freezing).
Relative humidity: 35 to 85% RH (non-condensing).
trait
Fast computing speed: It has a fast computing speed to meet the real-time control needs.
Rich features: Integrate a variety of functions, such as high-speed counters, pulse output, etc.
Easy to expand: All PCM series expansion modules can be extended, and the application scheme is flexible and rich.
High environmental resistance: dustproof, waterproof, oil-proof design, suitable for harsh industrial environments.
High precision measurement: High precision measurement with high precision technology developed by Keyence.
Multiple protection functions: With over current protection, over voltage protection, under voltage protection and other protection functions, improve the reliability and stability of the system.
