Description
Parameters and specifications
Accuracy: 0.2%, 0.5%
Power consumption: ≤3VA
Job stability: annual change < 0.2%
Power frequency withstand voltage: AC2.0kV/min.1mA
Insulation resistance: ≥ 20MΩ (DC500V)
Impulse voltage: 5kV (peak), 1.2/50μS
Response time: ≤350ms
Input range: DC0 to 5A, DC0 to 500V Optional
Overload capacity: Current: 2 times continuous, 20 times/SEC; Voltage: 2 times continuous
Output signal: DC0~5V, 1~5V, 0~20mA, 4~20mA, etc
Load resistance: Current output: RL≤600Ω; Voltage output: RL≥2KΩ
Working environment: -10 ~ 50℃, 20% ~ 90% no condensation
Storage environment: -40 ~ 70℃, 20% ~ 95% no condensation
Installation method: DIN(35mm) guide rail and M4 screws fixed
Dimensions: 55mm×75mm×120mm
Operating voltage: may include 24Vdc/120Vac (depending on application scenario)
Weight: 2KG (according to specific supplier information)
trait
High-precision measurement: May be equipped with high-precision sensors that can accurately measure relevant parameters.
Quick response: The ability to quickly catch and respond to changes.
Good stability: maintain accurate measurement results under different environmental conditions.
Multiple output options: Supports a variety of output signals for easy connection to different devices or systems.
Easy integration: It has a simple interface and integration scheme to facilitate system integration and expansion.
High reliability: able to operate stably in harsh industrial environments for a long time.
