Description
argument
Accuracy: 0.2%, 0.5%
Power consumption: ≤3VA
Job stability: annual change < 0.2%
Power frequency withstand voltage: AC2.0kV/min.1mA
Insulation resistance: ≥ 20MΩ (DC500V)
Impulse voltage: 5kV (peak), 1.2/50μS
Response time: ≤350ms
Input range: DC0 to 5A, DC0 to 500V Optional
Overload capacity: current 2 times continuous, 20 times/SEC; Voltage 2 times continuous
Output signal: DC0~5V, 1~5V, 0~20mA, 4~20mA, etc
Load resistance: current output RL≤600Ω; Voltage output RL≥2KΩ
Working environment: -10 ~ 50℃, 20% ~ 90% no condensation
Storage environment: -40 ~ 70℃, 20% ~ 95% no condensation
specification
Implementation standard: QB/441600 17 079-2001
Installation method: DIN(35mm) guide rail and M4 screws fixed
Dimensions: 55mm×75mm×120mm
Size and weight
Size: 55mm×75mm×120mm
Weight: May be 2KG or 1KG depending on the source
trait
High precision measurement: May be equipped with high precision pressure sensors that can accurately measure changes in dynamic pressure.
Fast response: The ability to quickly capture pressure changes and accurately measure them.
Good stability: maintain accurate measurement results under different environmental conditions.
Multiple output options: Support a variety of output signals, such as analog or digital signals, easy to connect to different devices or systems.
Easy integration: With a simple interface and integration scheme, you can easily connect with other systems or devices.
