Description
Parameters and specifications:
Processor: Power PC 8245,400 MHz.
Memory: 32 MB SDRAM and 16 MB flash.
Communication interface:
Twelve universal RS-232/RS-422/RS-485 serial line interfaces.
Four isolated RS-232/RS-422/RS-485 universal serial line interfaces.
Dual CAN bus interface (1 Mbps).
Dual Pro bus (12 Mbps).
A Serial Process bus (SPBus) interface for connecting RIO 400 remote I/O devices.
Dual 100 Mb Ethernet LAN connectors.
Power supply: Input voltage 24 V DC ±20.
Power consumption: Maximum 20 W.
Output frequency: 47/63.
Size and weight:
Dimensions: Height 355 mm, width 158 mm, depth 87 mm (as described in [1]). But in other search results, the size is described as 26157 (possibly another unit or measurement).
Weight: 1.35 kg (as described in [1]), but it is also described as 2.51 kg.
Series:
The RCU500 is part of the KONGSBERG family of process control modules.
Features:
The RCU500 is a single computer designed for process control and is software compatible with the RCU 400H control unit and the SBC 500 single board computer.
It has a built-in self-check (BIST) device and error reporting system, a watchdog with system status output, and built-in high temperature and cooling fan alarms.
The RCU500 is easy to install and replace, supports DIN standard rail mounting and plug-in connections, and features a front-facing LED status indicator.
The RCU500 is ready for redundant RCU operation, allowing for “hot replacement” in redundant systems.
Functions:
The RCU500 remote controller unit is mainly used for process control, such as dynamic positioning systems, container control systems and safety systems.
The RCU500 is part of KONGSBERG’s industrial digitization in multiple sectors such as maritime, oil and gas, renewable energy and utilities, Defense and space, providing advanced digital solutions to these industries.
