Description
Product Description:
The IS230PCAAH1A is a programmable control system for a range of industrial applications, including manufacturing, energy and transportation.
It is designed to provide reliable and efficient control of electrical equipment such as motors, pumps and valves.
The system is equipped with advanced features such as fault detection and diagnostic functions to ensure safe and efficient operation.
Parameters:
Input voltage: 24 VDC
Operating temperature: -40°C to +85°C
Memory: 64KB
Input quantity: 16
Output quantity: 16
Specifications:
Size: 17.71×13.77×7.87 cm
Series: Mark VIe
UL Certification: File E157382
CE certification: EN 61000-6-2:2005 and EN 61000-6-4:2007
FCC compliance: Part 15 Subpart B, Class A
Features:
The module is suitable for simplex, duplex and TMR systems.
PCAA signals are divided into two groups.
Most of the analog signal I/O required for gas turbine operation is provided by the Core analog (PCAA) module and the associated core analog (TCAS and TCAT) terminal boards.
Thermocouple input, 4-20 mA current loop I/O, seismic input, linear variable differential transformer (LVDT) excitation and input, pulse rate input, and servo coil output are all provided by PCAA and TCAT.
Function and use:
Provides core simulation functions for the Mark VIe system.
Control the operation of the gas turbine to ensure its safe and stable operation.
