Description
argument
Input DC power supply: 24VDC to 75VDC
Max. continuous current: 20A
Ambient temperature range: -30 to 65 degrees Celsius
Probe power supply: -24 volts DC, 12 mA load per sensor
Frame rates: 3.125, 6.25, 12.5, 25, 50, and 100 Hz
Communication protocol: Support RS232 communication (RS485 and CAN bus optional)
specification
Dimensions: 3.25 “high x 1.65” wide x 4.78 “deep
trait
High reliability: with temperature protection, over current, over voltage, under voltage protection, I2T current limit and other functions.
Multiple control modes: position control mode, speed control mode and torque control mode are supported.
Various operating modes: including network command mode, pulse/direction mode, analog signal mode and independent operation mode.
Network communication: Through RS232/RS485/CAN communication with the PC or the user’s host computer connected.
Vibration Monitoring function: Designed as a vibration monitoring package, it provides electrical interface function for collecting and reading proximity and vibration information.
Simple PLC function: Integrated simple PLC function, can logically control the input/output in network command mode and independent operation mode.
