Description
Parameters and Specifications:
–Channel Count: 8 RTD channels1
–A/D Converter Resolution: 14 bits1
–Common Mode Voltage Range: ±5 Volts1
–Maximum Lead Resistance: 15 Ω1
Dimensions and Weight:
–Dimensions: Approximately 34cm x 18cm x 10cm2, but note that the exact dimensions for the 336A4940CSP6 variant may differ slightly.
–Weight: Approximately 4.40 pounds (2kg) without packaging materials2.
Series:
- Part of GE’s Mark VIe series of industrial automation and control modules
Features:
–High-Resolution Inputs: Provides 14-bit resolution for accurate RTD temperature measurements1.
–Compatibility: Compatible with various RTD input terminal boards, such as TRTDH1D, H2D, and SRTD1.
–Ethernet Connectivity: Features two Ethernet ports for communication and network redundancy1.
–LED Indicators: Includes LED indicators for visual diagnostics2.
–CE Marking and UL Listing: Meets relevant safety and quality standards2.
Functions:
–Temperature Measurement: Measures temperature using RTD sensors, commonly used in industrial applications1.
–Signal Conditioning: Converts RTD signals into digital values that can be processed by automation systems1.
–System Integration: Integrates seamlessly with GE’s Mark VIe distributed control systems, enhancing system performance and reliability1.
–Diagnostics: Provides detailed diagnostic functions, including input limit testing and lockable diagnostic signals
