Description
argument
Driving voltage: AC 110V-220V
Adaptive current: below 4.2A
Outer diameter: 86mm
Suitable motor power: 43KW
Rated current: 23mA
specification
Type: Equal Angle constant torque subdivision driver
Series: Mark VI Speedtronic series
Structure: Pull-out
Communication interface: Etherner
Internal function: internal programmable, free to set the motion curve; Excellent multi-axis synchronization and high-precision master-slave following function; Electronic CAM curve can be customized; Supports RS485, CANopen, Profibus DP fieldbus communication
Size and weight
Height: 23mm
Door thickness: 42mm
Weight: 0.8KG
trait
Manual energy flow control: Use jumper pins to create a manual switch to direct the energy flow
Multiple Ethernet ports: There are multiple Ethernet ports as well as other styles of connection terminals, each of which is labeled with a purpose
Circuit cooling mechanism: There is a large black line for cooling the circuit board, equipped with tower and box condensers
Energy storage: Capacitors are used to generate an electrical field that stores electrical energy that can be used later on the circuit board
Connection and communication: Has several terminals that are used to connect the boards in place and allow communication between the boards
Additional features: Includes battery and SD card for extended functions
Redundant configuration: In the DCS system, it can be used for non-redundant, dual-redundant, and triple-redundant configurations
