IS200TREGH1BDC

Description

‌Parameters and Specifications‌:

–‌Brand‌: General Electric (GE)12
–‌Type‌: Gas Turbine Control System Card or Module12
–‌Operating Voltage‌: Compatible with 175VAC to 250VAC, 50Hz3
–‌Operating Temperature‌: -20°C to 55°C3
–‌Humidity‌: 90% relative humidity (non-condensing)3
–‌Output Frequency‌: 50/60Hz4
‌Dimensions and Weight‌:

–‌Dimensions‌: Approximately 10mm x 16mm x 23mm

‌Series‌:

• Part of GE’s gas turbine control system series, likely the VIe series1.
  ‌Features‌:

–‌High Safety‌: Designed with safety in mind4.
–‌Twelve Relays‌: Equipped with twelve relays, arranged in two rows of six, each with a silver metal wire on top12.
–‌Color Coding‌: Relays are color-coded white and black for easy identification12.
–‌Voltage Transformers‌: Includes two voltage transformers (PTS) for bus and generator voltage inputs1.
–‌DC-37 Pin Connector‌: Features a DC-37 pin connector for cable connection as a backup trip relay1.
‌Functions‌:

–‌Emergency Trip Protection‌: Serves as an emergency trip terminal board in gas turbine control systems1.
–‌Backup and Main Protection‌: Provides both backup and main protection functions to ensure the safe operation of gas turbines1.
–‌Condition Speed Signal Input‌: Accepts condition speed signals from I/O packs1.
–‌Integration‌: Integrates seamlessly into Mark VIe or Mark VleS control systems
