IS200TPROH1C

Description

argument
SSI data Bit number: A data value that defines how many bits of a data stream, ranging from 1 to 32.
The most important point (MSB) quantity: defines the first value of the bit position of the data in the data bit stream, ranging from 1 to 32.
Number of SSI clock bits: Set the number of bits that 7264 will read from the SSI sensor per interrogation, ranges from 1 to 32, must be greater than or equal to (most important digit + (number of SSI data bits -1)), the default value is 24 bits.
specification
Rated input: 0 ~ 20 kAac
Rated output: 0 ~ 20 madc, 0 ~ 5 vdc, 4 ~ 20 madc
Accuracy: Level 1.0
Linear range: 0 ~ 120%
Isolated voltage: 5000vdc/1 minute
Auxiliary power supply: +12vdc, ±12vdc, +24vdc
Operating temperature: -20℃ ~ +60℃
Temperature drift: <300ppm/℃
dimension
The integrator uses an S-shaped structure with a size of about length x width x height =86x70x73mm
It belongs to the Emergency Protection (TPRO) family developed by GE.
trait
Product input saturation: Due to the use of Rogowski principle, abandon the traditional transformer principle or Hall principle must be used in the magnetic core, so that the product input range can be large without affecting the performance.
Fast response time: the response time can reach the level of microseconds, which is suitable for fault recording in the power system.
Product frequency response width: the bandwidth range can reach more than 20khz, which is suitable for signal detection such as complex input waveform.
Good linearity: the linearity of the output can reach 0.2%, which can accurately reflect the size of the input signal.
High product accuracy: the overall accuracy is within 1%.
