Description
Specifications:
Input Voltage: 0-5 VDC
Output Voltage: 0-10 VDC
Output Current: 20mA
Operating Temperature: -40°C to 85°C
Humidity: 5% to 95%RH, non-condensing
Functions:
IS200EXAMG1A serves as an exciter attenuator module for the Mark VI excitation control system, providing bridge protection and attenuating signals from the field bus and exciter grounding detection module (EGDM)
Weight and Dimensions:
Weight: 1.5 pounds (0.7 kilograms)
Dimensions: 6.81 inches x 4.06 inches x 2.17 inches (173 x 103 x 55 mm)
Features:
Provides bridge protection for the excitation system1.
Attenuates signals from the field bus and EGDM
Communicates with the EX2100 excitation controller via the field bus
Designed with high reliability and stability for industrial environments
Application Areas:
IS200EXAMG1A is widely used in power generation, industrial motors, and public transportation systems
It is also applicable in chemical, paper, power, oil, and gas industries due to its robust performance and reliability
