Description
Parameters
- System Power Supply Voltage Range: 20 to 32V dc
- Input Quantity: 40 channels (for analog input modules)
- User-Defined Threshold: 4-off
- Input Current Range: 0-22mA
- Input Voltage Range: 0-6 Vdc
- Sample Update Time: 0.5 milliseconds
- Resolution: 3.9 microamperes (1/256 milliamperes)
- Safety Accuracy: ±1% of full scale (default threshold, above which will trigger 0x70nn series fault)
- Calibration Accuracy: 0.03%
- Recommended Input Channel Calibration Check Interval: 2 years
- Circuit Type: Fault-tolerant, fully triplicated
- Working Temperature: -40°C to +70°C (or -25°C to 70°C depending on source)
- Non-working Temperature: -25°C to 70°C
- Operating Humidity: 10–95% RH non-condensing
Specifications
- I/O Type: Digital input, digital output, analog input, analog output
- Number of Channels: 32 (general specification)
- Redundancy: Triple redundancy
- Isolation Voltage: 2500 Vrms
- Communication Protocol: Modbus TCP/IP
- Maximum Input/Output Current: 500mA
- Dimensions: 220 mm x 176 mm x 89 mm (or 100mm x 50mm x 25mm depending on source)
- Weight: 1.2KG (or 1.149kg depending on source)
Series
- ICS TRIPLEX Series
Features
- High Reliability: Triple redundancy design ensures system stability and reliability.
- Versatility: Supports digital and analog input/output, allowing for flexibility in various applications.
- Remote Monitoring and Control: Enables remote access and control through supported communication protocols.
- Ease of Use: Provides programmable logic control with user-friendly interfaces.
Applications
- ICS TRIPLEX T8431 is designed for critical applications in industries such as:
- Oil and Gas
- Chemical
- Power
- Pharmaceutical
- Nuclear Energy
- Industrial Automation
- Power Systems
- Petrochemical
- Logistics and Warehousing
