IC698CPE010-AA

Description

*‌Model‌: IC698CPE010-AA
*‌Manufacturer‌: Formerly GE Intelligent Platforms, now part of Emerson Automation Solutions
*‌Type‌: PACSystem RX7i Central Processor (CPU) Module
*‌Processor‌: 300MHz Celeron Microprocessor capable of floating-point calculations12
*‌Memory‌:

• 10MB Battery-Backed RAM
• 10MB Non-Volatile Flash Memory12
  *‌I/O Capacity‌: Supports up to 32K bits of discrete I/O and 32K words of analog I/O23
  ‌Dimensions and Weight‌:

*‌Approximate Dimensions‌: 48mm x 96mm x 118mm (L x W x H)5
*‌Weight‌:

• 0.5kg (approx.)6
• 1.2kg mentioned in one source
•
  ‌Series‌:

• Belongs to the PACSystem RX7i series of industrial automation controllers.
  ‌Features‌:

*‌High Performance‌: Capable of handling complex control logic and data processing tasks14.
*‌Comprehensive Communications‌: Equipped with two Ethernet ports, one RS-232 port, one RS-485 port, and a station manager port, supporting protocols like SRTP, Modbus TCP, and Modbus RTU23.
*‌Programmable‌: Supports multiple programming languages including C, ladder diagram, structured text, and function block diagram4.
*‌Flexible Connectivity‌: Allows integration with various I/O modules, communication modules, and HMI devices through the VME64 open architecture23.
*‌Reliable Storage‌: Provides 10MB of RAM and 10MB of non-volatile flash memory for program and data storage12.
‌Role‌:

• The IC698CPE010-AA CPU module serves as the heart of industrial automation systems, executing real-time control, data acquisition, analysis, motion control, human-machine interface, remote monitoring, and other high-performance, high-reliability control applications6.
• It is suitable for use in various industries including automotive, aerospace, food processing, pharmaceutical manufacturing, electric power, petrochemical, metallurgy, mechanical manufacturing, electronic manufacturing, and logistics
