Description
Parameters and Specifications:
Clock Speed: 64 MHz
Bit Size: 32-bit Floating Point
Memory: 1 Mbyte
Operating System Compatibility: Supports VME standard C.1, Windows, and MS-DOS
CPU Type: Equivalent to Intel’s 80486DX2
Discrete Inputs/Outputs: Up to 12K (mixed simplex)
Serial Port: RS-485 compatible with 15-pin D-type connector
Battery: Lithium battery for maintaining calendar clock, data, and program memories
Temperature Range (Operating): 0 to 60°C (32 to 140°F)
Temperature Range (Forced Air Cooling): 0 to 40°C (32 to 104°F)
Clock Accuracy: 3.5 seconds per day (max)
Internal Timing Accuracy: 0.01% (max)
Dimensions and Weight:
Size: Standard size for PLC backplane slot (exact dimensions not provided)
Weight: 4.00 lbs (1.81 kg)
Features:
High-Performance Processing: 64 MHz clock speed and 32-bit floating-point capability.
Large Memory: 1 Mbyte of battery-backed memory.
Flexible Connectivity: Single RS422/485 port for connectivity to other devices.
Multiple LEDs: Four green LEDs for indicating CPU status.
