Description
Features:
Industrial grade design: with lightning protection, overcurrent protection and surge protection.
Multiple power input: DC9-36V wide redundant dual power input, with DC1500V voltage isolation and reverse protection function.
Protection Class: IP30 protection class, using wavy aluminum reinforced housing and standard industrial 35mm rail mounting.
Multi-communication rate support: Support the dip switch to manually set all its standard rates or rate adaptive.
Status display: 6 two-color LED status indicators, power failure relay output alarm.
Functions:
The IC695PBM300 module is mainly used for data exchange through the Profibus network to support various applications in industrial automation systems, such as mechanical automation, robot control, packaging and logistics systems. It enables the PACSystems RX3i programmable automation controller to communicate with up to 125 DP slave stations for real-time data transmission and processing.
Parameters and specifications:
Type: Profibus DP master station module.
Data transfer: Supports data transfer sizes of 244 bytes of input and 244 bytes of output per device, with a maximum of 3.584 bytes of input and output data.
Communication capability: Supports communication of up to 125 DP slave stations.
Communication rate: All standard data rates are supported, including 9.6 kBit/s, 19.2 kBit/s, 93.75 kBit/s, 187.5 kBit/s, 500 kBit/s, 1.5 MBit/s, 3 MBit/s, 6 MBit/s, and 12 MBit/s.
Status information: Provides status information such as slave status bit array table, network diagnostic counter, DP master diagnostic counter, firmware module revision, and slave diagnostic address.
Firmware upgrades: Firmware upgrades are supported and received indirectly through the host controller via the WinLoader software utility.
Temperature range: Must operate in a temperature range of 0 to 60 degrees Celsius and storage temperature of -40 to 85 degrees Celsius.
