Description
Specifications and Parameters:
Ethernet Connectivity: The IC695ETM001 provides Ethernet connectivity with support for 10/100 Mbps transmission rates and auto-negotiation capabilities.
Processor Speed: It features an Ethernet processor speed of 200 MHz, ensuring efficient data handling and communication.
Protocols Supported: The module can execute protocols such as SRTP, Modbus TCP, and EGD over a four-layer TCP/IP stack.
IP Address: It supports one IP address for network communication.
Serial Port: Additionally, it includes an RS-232 serial port supporting data rates ranging from 1200 bps to 115,200 bps.
Functionality:
Ethernet Integration: The IC695ETM001 enables RX3i PACSystems controllers to communicate with other PACSystems devices, 90-series, and VersaMax controllers via Ethernet.
Data Exchange: It facilitates periodic data exchange through EGD, enabling read and write operations on controllers.
Time Synchronization: It can synchronize timestamps during EGD exchanges with SNTP time servers.
Diagnostics and Management: The module offers diagnostic tools and an integrated station manager accessible via Ethernet and serial connections for monitoring, control, and configuration.
Weight and Dimensions:
Weight: Approximately 0.9 kg to 1.2 kg, depending on the specific variant or manufacturer’s specifications.
Dimensions: Measuring approximately 100mm x 50mm x 20mm or 200mm in some configurations, it is designed for compact installation in RX3i slots.
