IC695ETM001

Description

Parameter Specifications

1. Power Supply: The IC695ETM001 operates on a 24V DC power supply, with a power consumption of approximately 10 – 15W. This power requirement is designed to ensure stable and efficient operation within industrial environments.
2. Communication Interface: It features an Ethernet communication interface that adheres to the standard IEEE 802.3. It supports a data transfer rate of up to 100Mbps, facilitating fast and reliable data exchange. It uses the Modbus TCP protocol, which is widely recognized in the industrial field for seamless integration with other devices in a network.
3. Processor and Memory: It is equipped with a microprocessor that enables quick data processing. It has 512KB of non – volatile memory for storing configuration data, program logic, and historical event logs. This memory ensures that the device retains important information even in the event of a power outage.
4. Operating Temperature Range: Designed to function within a temperature range of – 20°C to 60°C. This wide temperature tolerance allows it to be used in various industrial settings, including those with extreme temperature conditions.

Applications

1. Industrial Automation: In manufacturing plants, the IC695ETM001 can be used as a communication gateway between different control systems and devices. For example, it can connect a Programmable Logic Controller (PLC) to a Supervisory Control and Data Acquisition (SCADA) system, enabling real – time data transfer and remote control of the production process.
2. Process Control: In chemical and pharmaceutical industries, it can be used to monitor and control complex chemical processes. It can collect data from sensors measuring temperature, pressure, and flow rate, and transmit this data to a central control system for analysis and decision – making.
3. Building Automation: In commercial buildings, it can be integrated into the building management system. It can communicate with various building systems such as HVAC, lighting, and access control, enabling centralized monitoring and control for energy efficiency and security.

Weight and Dimensions

1. Weight: Approximately 0.8 kg, which is relatively light and easy to handle during installation and maintenance.
2. Dimensions: It has a compact design, with dimensions of about 180mm (length) x 120mm (width) x 70mm (height). This small size allows it to be easily installed in standard control cabinets or limited – space enclosures.

Features

1. Ethernet Connectivity: The high – speed Ethernet interface with Modbus TCP support enables seamless integration into industrial networks, allowing for easy communication with other devices and systems.
2. User – friendly Configuration: It comes with user – friendly configuration software that simplifies the setup process. Users can easily configure communication parameters, network settings, and data mapping, reducing the time and effort required for installation.
3. Diagnostic Functions: It is equipped with built – in diagnostic functions that can detect faults in the communication interface, network connectivity, and internal components. This helps in quick troubleshooting and reduces system downtime.

Stability and Reliability

1. Robust Construction: Built with high – quality components and a durable enclosure, it can withstand industrial vibrations, shocks, and electromagnetic interference.
2. Redundancy Options: Some configurations may support redundant power supplies or communication links, providing an additional layer of reliability in case of a single – point failure.
3. Long – term Testing: Through extensive long – term testing, it has been proven to have a stable and reliable performance over time, with a low failure rate.
