Description
I/O capability:
It can accommodate discrete input and output signals up to 32K bits
32K word analog input and output capacity
Block support: Up to 512 blocks are supported, each block up to 128 KB
3. Size and weight
Dimensions: 170mm x 105mm x 32mm
Weight: About 120g
1. Parameters
Processor speed: 1.1 GHz Atom processor
Memory: 10 MB of non-volatile flash
Boolean logic execution speed: 0.72 ms/k
Power requirements: 3.3 volts DC, 5 volts DC or 24 volts DC
2. Specifications
Communication interface:
Embedded Ethernet interface supports 10Mb/ s and 100Mb/ s connections
RS-485 and RS-232 serial ports
USB-A 2.0 main port (for configuring applications and data transfer)
Protocol support:
The Ethernet port supports the SRTP protocol and the data transfer rate is 10/100 Mbaud
The serial interface supports SNP, serial I/O, Modbus RTU slave and Modbus master protocols
The fieldbuses supported by the controller include PROFINET, EGD, Modbus TCP server and client, Genius, and Profibus DP
