Description
Step 5: Characteristics
High performance: Processors based on high performance and fast computing speed
Mass storage: 10 MB of battery-operated memory is provided to ensure no data loss
Multiple communication options: Supports a variety of communication protocols and interfaces, including Ethernet, RS232, RS485, etc
Programming flexibility: Compatible with multiple IEC languages as well as C programming languages, supporting ladder, structured text, C or functional block diagram programming languages
Advanced features: Provides hot swap, advanced diagnostic tools, real-time clock, and dynamic data backup facilities
User friendly: LED indicator for system status verification and USB-A 2.0 main port for configuring and downloading applications
1. Parameters
Processor speed: 1.1 GHz Atom processor
Memory: 10 MB battery-powered non-volatile flash memory
Boolean logic execution speed: 0.72 ms/k
Communication interface: two serial ports (RS232 and RS485) and an Ethernet communication interface
I/O capacity:
Discrete input/output: up to 32K bits
Analog input/output: 32K words
Block support: Up to 512 blocks, each block up to 128 KB
2. Specifications
Power requirements: 3.3 volts DC, 5 volts DC or 24 volts DC
Data transfer rate:
Ethernet port: 10/100 Mbaud, with automatic negotiation function
Serial port: Rates are not specified, but are generally compatible with RS232 and RS485 standards
Supported communication protocols: SRTP (Ethernet), SNP, serial I/O, Modbus slave protocol and Modbus master protocol
3. Size and weight
Dimensions: 170mm x 105mm x 32mm
Weight: About 120g
