Description
Parameters and specifications:
Series: GE Fanuc RX3i PACSystems series.
Number of slots: 12.
Supported I/O types: PCI (IC695) and serial (IC694) based I/O.
Power specifications: Internal power supplies use 240 mA@5 VDC and 600 mA@3.3VDC.
Internal power consumption rating: 600 mA at 3.3 V DC and 240 mA at 5 V DC.
Size:
The physical dimensions are 5.57 x 18.01 x 5.80 inches
Features:
Dual bus backplane: supports both PCI and high-speed serial devices.
Hot-swap support: Allows maintenance activities such as module replacement and integrity verification while powered on.
Optional modules: Support GE series 90-30 I/O modules and optional modules.
Backboard options: Available backboard options include a controller backboard and an Ethernet extension backboard.
Installation requirements: Must be mounted horizontally and allow at least 4 inches (102 mm) of space on all sides for heat dissipation.
Connection: There is a patch panel on the left side for connecting isolated +24 V DC input voltage.
Protection Level: Can be installed in a protective housing with protection level IP 54 or higher.
Functions:
The IC695CHS012 is a universal backplane that provides the housing for the RX3i modules and connections. It supports a variety of I/O modules and option modules and is one of the key components in building industrial automation control systems.
