Description
Parameters and specifications
Brand: Formerly manufactured for GE Intelligent Platform (GE IP), now part of Emerson Automation.
Model: IC695ALG708.
Output channels: Has eight output channels that can be configured for 0 to 20mA and 4 to 20mA current signals as well as ±10V and 0 to 10V voltage signals.
Installation position: Install on the RX3i backplane.
ADC conversion resolution: 15.6-15.9 bits.
Analog output resolution: 14.9-15.9 bits, depending on the configured output signal.
Power requirements: The system requires an external 24 VDC power supply.
series
Series: Analog output modules belonging to the PACsystem RX3i and RX8i Programmable Automation controller (PAC) series.
trait
Alarm Settings: Individual alarm Settings can be set for each channel, such as extremely low, extremely low, extremely high, and extremely high alarms.
Output clamping: Each output can also be clamped at specific high and low points, which is useful when the output channel is linked to the proportional + integral + differential (PID) controller output.
Output bias: Output bias can be added to fine-tune or manually adjust the output to the user’s desired level.
Module failure reporting: Has a built-in module failure reporting function and retains the last status or output default Settings.
Compatibility: Compatible with the universal backplane of RX3i systems, any RX3i CPU (firmware version 3.5 or higher) can be used with it.
effect
Analog signal output: As an analog output module for PACsystem RX3i and RX8i Programmable Automation controllers (PACS), it is used to provide analog signals configured for different current and voltage output ranges.
Industrial automation: In industrial automation systems, used to monitor and control various equipment and processes, such as temperature, pressure, flow, etc.
