Description
Parameters and specifications:
Channel type: Has 16 single-ended input or 8 differential input channels.
Signal compatibility: Compatible with 0 to 20mA, 4 to 20mA ±20mA current signals and ±10V, 0 to 10V, ±5V, 0 to 5V, 1 to 5V voltage signals.
Conversion resolution: 24-bit ADC conversion resolution.
Alarm Settings: Each channel can be individually configured with alarm Settings, including very low, low, high and extremely high alarms, and positive and negative change rates can also be included.
Protection: With open detection, overvoltage and overcurrent protection, each channel can also be configured with alarm Settings.
Size and weight:
Dimensions: 170mm x 105mm x 32mm.
Features:
Non-isolated differential analog input: This means that it can process differential signals and that its input channel is not electrically isolated.
High conversion rate: Use a 24-bit analog-to-digital converter (ADC) to provide high-precision analog data conversion.
Channel filters: Includes a variety of optional filter configurations (8Hz, 12Hz, 16Hz, 40Hz, 200Hz, and 500Hz) to stabilize and minimize fluctuations.
