IC695ALG600-AB

Description

Parameters and specifications
Series: A family of universal analog input modules belonging to the GE Fanuc PACSystems RX3i PAC platform.
Input signal support: voltage, current, resistance and other input signals, and support thermocouple and resistance temperature detector (RTD).
Channel configuration: With two groups of four channels each, can be configured as any combination of input signals.
Supported signal range: including 0-20 mA, 4-20 mA, +/-20 mA current signal; +50mV, + 150mV, 0-5V, 1-5V, 0-10V, +10V voltage signal; 0 to 250/500/1000/2000/3000/4000 ohm resistance signal; PT 385/3916, N 618/672, NiFe 518, CU 426 RTD sensors; B, C, E, J, K, N, R, S, T thermocouple input.
Installation and configuration: Installed on an RX3i universal backplane, requires firmware version 2.80 or later and configured using Proficy Machine Edition (PME) version 5.0 SP1A LD-PLC Hotfix 1 or later.
Size and weight
Size and weight: Specific size and weight information is not given directly in the search results.
trait
Multi-signal support: Able to handle multiple input signal types, including voltage, current, resistance, thermocouple, etc.
High flexibility: Each channel can be set up independently to support different signal ranges.
High reliability: Support for flash memory and status LED status indicators for future upgrades.
effect
Temperature detection: As a resistance temperature detector (RTD) input module, the IC695ALG600-AB is primarily used for temperature detection, especially in industrial automation and control systems.
Industrial Automation: On the PACSystems RX3i PAC platform, it works with other components to enable industrial automation and control functions.
