Product Description
The IC694MDL645 is a 24-volt DC positive/negative logic input module designed for use with the RX3i Programmable Logic Controller system. The module provides 32 discrete input points in four isolated groups of eight points each.
Product Parameters
– **Voltage Rating**: 24 volts DC
– **Input Current**: 5mA maximum per point
– **Input Impedance**: 3.9kΩ minimum
– **Isolation**: 1500 volts DC between field side and logic side
Specifications
– **Dimensions**: 4.92″ H x 1.77″ W x 5.12″ D (125mm x 45mm x 130mm)
– **Weight**: 0.5 lbs. (0.23 kg)
– **Operating Temperature**: 0°C to 60°C
– **Storage Temperature**: -40°C to 85°C
