Description
Size and weight:
Weight: 1.81 kg or 2KG depending on data.
Series:
GE’s Series 90-30 series Programmable logic controllers (PLCS).
Features:
With an embedded Ethernet controller, it supports communication speeds of up to 100 Mbps.
It comes with 240 KB of user-configurable memory, 4K I/O, and eight racks.
It has 2048 fixed discrete input and output points and a discrete global storage capacity of 1280 bits.
The module’s register memory can be configured with 128 to 32640 words.
It is equipped with a processor that performs user-written control logic and operations.
Supports different programming languages and can handle floating-point data.
It can be configured with VersaPro or CIMPLICITY machine edition logic software.
Functions:
The IC693CPU374 is a programmable logic controller (PLC) for controlling and monitoring various devices and processes.
It supports modular, programmable control systems that respond quickly to real-time applications with high reliability and stability, and can work in harsh industrial environments.
Can be used with a variety of input/output modules to connect and monitor sensors, actuators and other devices.
Provides logic control functions that allow users to write and execute logic programs to perform various actions based on input state.
It is equipped with multiple communication interfaces, such as Ethernet interfaces, for data exchange and communication with other PLC, computer, HMI and other devices.
Parameters and specifications:
Manufacturer: GE Fanuc
Product number: IC693CPU374
CPU Type: single-slot CPU module with embedded Ethernet interface
Processor speed: 133 MHz
Processor type: Embedded 586
Typical scan rate: 0.15 ms per 1K logic (Boolean contacts)
Storage type: RAM and Flash
User memory (total) : 240KB
Protocol support: SRTP and Ethernet Global Data (EGD), Modbus/TCP client/server protocols
Built-in Ethernet communication: Ethernet (built-in) – 10/100 base-T/TX Ethernet switch
Number of Ethernet ports: two
Number of IP addresses: one
Operating temperature: 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
Storage temperature: -40 ℃ to +85 ℃
Institutional certification: UL508, C-UL (Level 1, Zone 2, A, B, C, D), CE mark
Rated power: 7.4 watts
Supply voltage: 5 V DC
