IC693CPU374

Description

trait
High performance: With fast processing speed and large user memory, it is suitable for handling complex logic and control tasks.
Flexible communication: supports a variety of communication protocols and interfaces to facilitate data exchange and communication with other devices and systems.
Programmability: Support for a variety of programming languages, such as VersaPro or CIMPLICITY machine logic software, so that users can develop and modify programs according to their needs.

specification
Communication port:
An embedded Ethernet controller supports communication speeds of up to 100 Mbps with built-in switches.
SRTP and Ethernet global data as well as Modbus/TCP client/server protocols are supported.
Two Ethernet communication ports, support 10/100 Mbps transmission speed, with automatic sensing function.
Optional RS485 communication port.
Power Supply:
Rated voltage: 5V DC.
Rated power: 7.4 watts.
Power consumption: Some data shows 3W, but it should be noted that this may be the power consumption under specific conditions.
Working temperature: 0 to 60 degrees Celsius.
Storage temperature: -40 to 85 degrees Celsius.

argument
Processor: AMD SC250 or AMD SC520 (different terms exist), built-in microprocessor, embedded 586 processor.
Processing speed: 133 MHz.
Typical scan rate: 0.15 ms per 1K logic.
User memory: 240 KB, configurable.
I/O points: 2048 fixed discrete input and output points.
Discrete global storage capacity: 1280 bits.
Register memory: can be configured from 128 to 32640 words.
System registers: 28 fixed system registers with timers and counters.
