IC693CPU374

¥6,035.00

Parameters and specifications
Processor: AMD SC250 or embedded 586 processor with processing speed of 133 MHz.
User memory: 240 KB, configurable for storage.
I/O points: 2048 fixed discrete input and output points, support for up to 4096 I/ OS (different models may vary).
Global storage capacity: 1280 bits.
Register memory: can be configured from 128 to 32640 words.
System registers: 28 fixed system registers with timers and counters.
Communication speed: The embedded Ethernet controller supports communication speeds up to 100 Mbps.

Category:

Description

effect
IC693CPU374 as a PLC module, the main role is to host user programs in industrial automation and process control systems, execute logic and manage data exchange. By connecting with various input/output devices, sensors, actuators, etc., it can monitor and control the production process and improve production efficiency and product quality.

trait
Embedded Ethernet controller: Supports SRTP and Ethernet global data as well as Modbus/TCP client/server protocols.
High performance: With fast computing power and large throughput capacity.
Versatile: Supports different programming languages, can handle floating-point data, and comes with RAM and flash memory for storage.
Scalability: Comes with one CPU backboard and seven extension or remote backboards, supporting different communication options and fieldbuses.
Diagnosis function: Supports Web diagnosis for easy troubleshooting.

Parameters and specifications
Processor: AMD SC250 or embedded 586 processor with processing speed of 133 MHz.
User memory: 240 KB, configurable for storage.
I/O points: 2048 fixed discrete input and output points, support for up to 4096 I/ OS (different models may vary).
Global storage capacity: 1280 bits.
Register memory: can be configured from 128 to 32640 words.
System registers: 28 fixed system registers with timers and counters.
Communication speed: The embedded Ethernet controller supports communication speeds up to 100 Mbps.
Power supply: 5 volts DC voltage supply, rated at 7.4 watts (but some information indicates that a high-load power supply may be required).
Operating temperature: 0 to 60 degrees Celsius (working environment), can be stored between -40 and 85 degrees Celsius when not in use.
