Description
Parameters and specifications
Features:
8 single-ended analog voltage outputs.
Output voltage range: +/-10 V or 0 to 10 V.
14-bit resolution.
Amplitude data size: 14 bits.
Electrical parameters:
Input voltage: 18 to 30 VDC
Backplane current: 170 mA per channel.
Output current (in some situations) : up to 10A
Communication interface:
Receives engineering unit output data (BIU) from the bus interface.
Other parameters:
Parameters such as operating temperature, storage temperature, and ambient humidity may vary depending on the application scenario, but are generally applicable to industrial environments.
Size and weight
Dimensions: 149.2 x 44.45 x 115.6 mm (5.875 x 1.75 x 4.55 inches).
Weight: Not given directly, but based on size and material, it is likely to be around a few hundred grams to a kilogram.
series
Part of GE Fanuc’s (now Emerson) family of Genius field control stations.
trait
Multi-channel output: Provides 8 independent analog output channels, each of which can be configured and controlled independently.
High accuracy and stability: With high accuracy and stability, it can provide a reliable output signal.
Flexible configuration: Users can configure modules and set parameters according to specific application requirements.
Anti-noise isolation channel: ensure signal stability and accuracy.
LED indicator: can display module status, such as normal operation, intermittent blinking (module fault).
Channel Activity feature: Allows an operator to configure a single channel as active or inactive.
